Model No. |
P5070DC |
| Cutting size |
500mm*700mm |
|
Cutting speed |
1mm/s~800mm /s |
|
Cutting thickness |
Max 1.2mm |
|
Cutting force |
1000g |
|
Cutting material |
PET, PVC, cardboard, self-adhesivefilm, fiber composites, and other materials |
|
Blade |
Dual blade,cutting & creasing |
|
Scan mark way |
Camera scan position system |
|
Material fixing way |
1.1KW Vacuum adsorption |
|
Operation Method |
Flatbed Cutting |
|
Driver |
Stepper motor |
|
Cutting precision |
士0.15mm |
|
Repeatable Precision |
≦0.05mm |
|
Cutting circle diameter |
≥1mm |
|
Interface |
USB/U-Disc port/Ethernet port |
|
Compatible software |
Signmaster, Al, Autocad, Coreldraw etc |
|
Command |
HPGL compatible format |
|
CNC panel |
Multi-language LCD touch panel |
|
Transmission method |
Imported belt |
|
Machine dimensions |
1290*865*965mm |
|
Operating voltage and power |
DC220V/110V士10%, 50HZ/60HZ |
