Model |
TL-1901T |
|
Print Head |
1Pcs -I3200 Epson Printhead 1Pcs-11600 Epson Printhead 1Pcs-Xp600 Epson Printhead |
|
Printing Speed |
3pass 360x1800 dpi 25㎡/h 6pass 360x1800 dpi 13㎡/h 6pass 360x1080 dpi 12㎡/h 4pass 720x1200 dpi 20㎡/h 8pass 720x1200 dpi 11㎡/h 8pass 720x720 dpi 10㎡/h
6pass 720x1800 dpi 13㎡/h 12pass 720x1800 dpi 8㎡/h 12pass 720x1080 dpi 6㎡/h |
|
Color Config. |
C M Y K |
|
Printing Width |
1900mm 74.8" |
|
Media Type |
Flex Banner, PP, Vinyl, PVC Film, Ceiling Film, Fabric, One Way Vision, Canvas, Window Film, Mesh Etc |
|
Ink type |
Eco Solvent Ink/Water Based Ink |
|
Ink Droplet Size |
3.8-5.5-8.7pl/4.5-9-20-40pl |
|
Ink Supply System |
Bulk Ink System With Ink Cartridges |
|
Rip Software |
RIIN / Maintop / Flexi/(Optional） |
|
Heating System |
Intelligent Front/Rear Control Heating, Optional Modes: Preheating/Printing Heating |
|
Environment |
Temperature 20-28 ℃/ Humidity 38-65 ℃ |
|
Feed & Take Up |
Damping Feeding, Constant Tension Take-up System |
|
Drying System |
Infrared Intelligent Heating |
|
Power |
Pre-heating 150W, Post-heating 150W,Equipment 500W,Dryer 1000w |
|
Machine Size & N.W. |
2920MM(L)x830MM(W)x1370MM(H)&180kg |
|
Package Size & G.W. |
3130MM(L)x690MM(W)x630MM(H)&220kg |
