Product Model |
HN-1325H |
|
Laser Power Configuration |
150W + 1500W Fiber / 300W + 2000W Fiber / 500W + 3000W Fiber |
|
Working Area |
X: 1300mm × Y: 2500mm |
|
Laser Type |
Raycus or Max Fiber source + CO₂ Laser Tube |
|
Laser Wavelength |
1064nm |
|
Max. Cutting Thickness (Material-Dependent) |
Acrylic ≤ 20mm / Acrylic ≤ 25mm / Acrylic ≤ 30mm Stainless Steel ≤ 3mm / Stainless Steel ≤ 4mm / Stainless Steel ≤ 5mm |
|
Positioning Method |
Red Dot Positioning |
|
Cooling Method |
Industrial Recirculating Water Chiller |
|
Cutting Kerf Width (Material-Dependent) |
≤ 0.3mm |
|
Total Power |
5.0KW / 6.5KW / 8.0KW |
|
Power Supply |
220V/380V, 50/60Hz, ±10% |
|
Machine Safety Features |
Water Circulation Protection |
