1.Suitable for flat embroidery, cap embroidery and finished garments embroidery, T-shirt embroidery, logo embroidery etc.
2. Embroidery area: 500mm*350mm 19.7"13.8"
3. Controller: 10" Touch Screen Dahao A15 System,User-Friendly Interface
4. High speed specialized cap embroidery heads,with double cam,double lever, by motorized jump.
5. Automatic thread trimmer
6. The running speed:100- 1200rpm
7. 280 degree Wide cap frame unit
8. Automatic color change and thread break detection
9. Start, Stop and emergency Stop Button
10.Design Tracing Available
11.One-Step Tracing
12. 10'' touch screen display control panel, showing real time stitching
13.Memory size: 500 Patterns,200 Million stitches
14. Computer Reads Multiple Design Formats such as DST.DSB And More.
15. USB port
16.Networkable And Wi-Fi capable
17. Control system can be updated easily
18.Multi-languages: Chinese, English, Spanish, Turkish, Russian.. French, Portuguese, Arabic,Thai, Italian,German, Dutch,Polish
19. Electricity: 110V/60Hz or 220V/50Hz Self adaptable
20.Equip With Laser Positioning
21.Woodencase Packing.
22.Machine Size: 1090x750x1530MM Packing Size:850x835x900mm
Packing list
| Item | QTY. | Item | QTY. | |
| complete machine | 1set | bobbin winder | 1set | |
| body stand | 1set | owner’s manual | 1pc | |
| front working table | 1set | tool box | 1pc | |
| cap station | 1set | needle 10pcs/pack | 1pack | |
| cap frame（hoop） | 2pcs | machine-oil | 1pc | |
| cap driver | 1set | bobbin case | 1pc | |
| round hoop 90mm | 2pcs | bobbin core | 2pcs | |
| round hoop 120mm | 2pcs | power cable | 1pc | |
| round hoop 150mm | 2pcs | needle plate screw | 2pcs | |
| round hoop 200mm | 2pcs | long flat nose pliers | 1pc | |
| square hoop 290x290mm | 2pcs | forceps | 1pc | |
| rectangle hoop 550x360mm | 1pcs | hexagonal socket wrench | 1set | |
| pantograph 380x530mm | 1pcs | thread picker | 1pc | |
| hoop support | 1set | 4*25 inner hexagon | 2pcs | |
| plastic table support | 1pc | 4*12 inner hexagon | 2pcs | |
| flash disk（USB） | 1pc | 4*8 cross screw driver | 2pcs | |
| screw knife - | 1pc | 5.5-7 wrench | 1pc | |
| screw knife + | 1pc | 8-10 wrench | 1pc | |
| screw knife – 5x125 | 1pc | 22-24 wrench | 1pc | |
| screw knife + 5x125 | 1pc | scissors | 1pc | |
| S#5.5mm | 1pc | Frame clip | 1pcs | |
|
Extra as Bonus: Needles x 10 pack, Thread x 10 rolls,lining paper(0.9mx50m) x1 roll, bottom thread x 2 rolls |
||||
