creasing, hot pressing, cold pressing, CNC cutting, round corner cutting, papers managing and hot binding, hard cover making,
cover corner cutting, cover edge folding, cover grooving. comes with air pump.
Album and photo book making machine Feature:
1. 12 functions are combined in one machine with small size, it takes less space and shipping cost to export city, and several functions can be working together by 3-4 workers.
2. Fully automated operation. The combination of electric & pneumatic principle can make technology standard, making sure exactness of making album, simple operation and speed up working.
3. Innovative corner cutting mode completely solve the uneven problems.
4. CNC cutter with infrared ray control make the very precisely fine product.
5. Aluminum alloy blade creases exquisite lines and will not damage the surface of pictures.
6.With design of both cold and hot pressing, grooving heating and adjustable creasing width.
|
10 in1 album making machine |
||
|
Operation principle |
eletric and pneumati |
|
|
Wegiht |
N.W280Kg G.W340Kg |
|
|
Machine size |
1180x980x1500mm |
|
|
Max size album |
18 inch x 24 inch(open) |
|
|
Creasing blade |
Creasing blade material |
45 |
|
Max size of creasing |
480mm |
|
|
Creasing blade width |
1.2mm/1.7mm |
|
|
Binding |
Binding material |
Alminum |
|
Max size of binding |
480cm |
|
|
Max height of binding |
45mm |
|
|
Cover cutting |
R3-R10 to choice |
|
|
Max size of cover making |
18 inch 24 inch(open) |
|
|
Pressing |
Cold/hot |
|
|
Pressing temperature |
60-80 |
|
|
Pressing size |
550x390mm |
|
|
Pressing height |
200mm |
|
|
Air compressor model |
LJ-1509 |
|
|
Pump efficiency |
45L/min |
|
|
Paper cutter model |
460CNC |
|
|
Protection of paper cutter |
infrared |
|
|
Cutting size |
460x460mm |
|
|
Cutting height |
50mm |
|
|
Pressing paper |
Independent motor |
|
|
Working pressure |
0.7MPa |
|
|
Grooving size of cover |
450(0.1-40)mm to choice |
|
|
Grooving blade width |
2mm |
|
|
Function: creasing,cold/hot binding,cold/hot pressing,460CNC paper cutter,cover cutting,cover making,cover pressing,cover grooving,air compressor |
||
