Model |
LB-F200 |
|
Function |
Auto feed, Auto Slot, V notch, Flange, Auto Bend |
|
Material |
stainless steel, galvanized plate, aluminum plate, iron |
|
Material Width |
20-200mm (0.787-7.87 inch) |
|
Slotting method |
Plane cutter |
|
Material thickness |
Flat aluminum: 0.3 - 1.2 mm/ SS : 0.3-1.2mm / Galvanized sheet: 0.4-1.2mm |
|
Flanging thickness |
1.0mm （0.039 inch） |
|
Flanging width |
10mm (0.40”) |
|
Minimum Bending Radius |
5mm |
|
Notching angle |
30° / 120° |
|
Support format |
AI/PLT/DXF/NC |
|
Input voltage |
220V 50Hz 1 phase |
|
Air pressure |
0.6-0.8MPA |
|
Total power |
4.5KW |
|
Driver |
Powerful 750w servo motor |
