Model |
G3208-UV |
|
|
Printing Width |
3200mm 10.5ft |
|
|
Print Head |
8Pcs - 1024A Konica Printhead [2*CMYK] |
8Pcs - 1024i Konica Printhead [2*CMYK] |
|
Printing Speed |
Draft - 480x1080dpi 72m²/h Production - 480 X1440dpi 58m²h
High-res - 480x1080dpi 40m²/h
Photo - 480x1440dpi 30m²/h |
Draft - 540x1080dpi 67.5m²/h
Production - 540x1440dpi 53.5m²/h
High-res - 540x1080dpi 37m²/h
Photo - 540x1440dpi 28.5m²/h |
|
Color Config. |
C、M、Y、K、W |
|
|
Ink Droplet Size |
6pl |
|
|
Ink type |
UV Ink |
|
|
Printhead Control |
In software Auto Adjustment on Printhead Temperature And Voltage |
|
|
Media Type |
Flex banner,Soft banner,coated banner,Backlit banner, Vinyl, Film,PVC,PP Etc |
|
|
Image Format |
TIFF、JPG、 EPS、PDF |
|
|
Rip Software |
RlIN / Maintop / Photoprint/(Optional) |
|
|
Power |
UV Lamp 2000W / Equipment 2000W |
|
|
Feed & Take Up |
High-precision Feeding System,Optional Take-up System |
|
|
Environment |
Temperature 20-28°C/ Humidity 38-65 °C |
|
|
Machine Size & N.W. |
4810MM(L)x935MM(W)x1450MM(H) 950kg |
|
|
Package Size & G.W. |
4994MM(L)x1064MM(W)x1672MM(H) 1100kg |
|
